Aluminum 113 push out casement windows system with America CMECH hardware
Product Information
A value for money exterior window with a narrow border and flat frame design that conforms to the minimalist style of time and meets the mainstream of minimalist luxury design.
Products Specifications
|
Thermal Insulation |
2.3W/㎡K |
Profile |
frame width 1.8mm |
|
Acoustic Performance |
<45DB |
Insulation strip |
PA66GF25-17mm High performance single cavity insulation strip |
|
Air Tightness |
≦0.4m³(㎡h) |
Glass |
5mm+20A+5mmFireproof tempered glass |
|
Wind Load Resistance |
>5Kpa |
Colour |
Aksu Powder coating: Grey ,coffee ,Black crystal sand,Ceramic White,Smooth white,Other colors can be customized |
|
Water Penetration |
≧500PA |
Handware |
CMECH hardware |
|
Warranty |
3-5 Years |
Opening Style |
casement push out |
|
Application |
Residential, Commercial |
|
|
Product details one
The injection type Angle is easy to maintain the stability of the product structure, improve the sealing, easy to install and transport, and reduce the maintenance cost.
Product details two
The internal and external double-sided flat frame design reduces the risk of aging due to the reduced contact between the sealing strip and the outside, thereby extending the service life of the window.
Product details three
Equipped with PA66 multi cavity heat insulation strip, it has good anti-aging performance, is not easy to crack or bulge, and has a long service life.
Product details four
Equipped with 304 stainless steel mesh for mosquito protection, the 304 mesh is made of high-quality stainless steel material, which has excellent corrosion resistance and heat resistance, is not easy to rust, and has a long service life.
