Product details of the horizontal sliding double glazed windows
Quick Detail
Foshan Imlang door and window Co, Ltd. adopts advanced production technology during the process of manufacturing horizontal sliding double glazed windows. The product is reliable in quality because it is produced and tested according to the requirements of widely recognized quality standards. IMLANG is able to offer horizontal sliding double glazed windows for customers.
Product Introduction
IMLANG Door And Window's horizontal sliding double glazed windows has better performances, as shown below.
Product Information
Our Oscar bridge sliding window pursues ultimate quality and is the perfect choice for sealing balconies. The profile wall thickness is 3.0, ensuring the stability and safety of the window frame, allowing you to freely control the opening method and imagine the natural wind.
Guangdong Xinyi tempered glass, combined with extremely narrow light enterprise design, maximizes indoor and outdoor visibility, bringing a transparent and bright living environment. The straight and hidden drainage multi-channel drainage structure meets your pursuit of comfortable and beautiful living quality.
Products Specifications
|
Thermal Insulation |
2.3W/㎡K |
Profile |
1.5mm frame fan thickness |
|
Acoustic Performance |
<45DB |
Insulation strip |
PA66GF25-20mm High performance single cavity insulation strip |
|
Air Tightness |
≦0.4m³(㎡h) |
Glass |
Double sided Sealant strip 5mm+20A+5mm toughened glass |
|
Wind Load Resistance |
>5Kpa |
Colour |
Aksu Powder coating: Grey ,coffee ,Black crystal sand,Ceramic White,Smooth white,Other colors can be customized |
|
Water Penetration |
≧500PA |
Handware |
Imlang customized pulley, Imlange customized buckle lock |
|
Warranty |
3-5 Years |
Opening Style |
Sliding |
|
Application |
Residential, Commercial |
|
|
Product details one
Standard aluminium window system for international requirements,1.5mm profile wall thickness, 5mm+20A+5mm large hollow.The original quartz stone glass, filled with argon gas in the middle, can reduce the risk of glass self-explosion caused by thermal expansion and contraction, increase the anti-collision ability of insulating glass, and more sound insulation and energy saving
Product details two
The sealing groove and decorative strip are made of Hermes orange contrasting color, which is fashionable and beautiful.Sealing slot can effectively prevent external pollutants from entering the room, low maintenance cost, energy saving and environmental protection
Product details three
The glass fan adopts a double 316stainless steel track and four pulley design, which is lightweight and smooth to push and pull, and extremely quiet.
Product details four
The product has good sealing, salt spray resistance, beautiful appearance, wide field of vision.
Product details Five
The combination of direct and hidden drainage channels greatly improves drainage efficiency, effectively avoiding water accumulation and rainwater backflow. Beautiful and smooth drainage
Company Advantages
Foshan Imlang door and window Co, Ltd. is located in We are a comprehensive enterprise integrating production, processing, marketing and trade. And our main business is IMLANG Door And Window makes best effort to becoming a world-recognized first-class enterprise. We take 'producing high-quality products' as the responsibility and 'being efficient, pragmatic and innovative' as the business philosophy. Besides, we insist on the principle of 'high quality guarantees consumers' interests and honesty protects the interests of partners'. Our company has established an experienced team of professionals in all ages. They provide internal motivation for our steady development. IMLANG Door And Window can provide customers with one-stop solutions of high quality, and meet customers' needs to the greatest extent.
Our products are available in various types and reasonable price. Welcome people from all walks of life to inquire and discuss business.
